Manatec DL 65 PREMIUM + Computerised Wheel Balancer
This wheel balancer is perfect for car and LCV wheels, offering Normal and Fine measurement modes, seven alloy wheel functions, and a live balancing display. It features automatic rim measurement, unit conversion, and quick wheel mounting. Additional highlights include over-voltage protection, self-calibration, and error display. Premium+ models add laser weight positioning and an inner plane torchlight for precision.
- SKU: Wheel Balancer
- Category: Heavy Machineries & Equipment
- Suitable for Car and LCV wheels
- Two modes of measurement – Normal & Fine
* Seven modes of Alloy wheel functions
* Graphical user interface for live balancing
* Option for “grams / “ounces” unit conversion
* Automatic distance input
* Rim parameter value entry through wheel rotation
* Over voltage & over load protection circuit
* Universal AC input socket
* Self calibration (when calibration error is displayed)
* Self checking on-line error display
* Adjustable unbalance threshold (weight cut off)
* Mid-centering device with Quick change lock nut to ensure fast mounting & removal of wheels
* Mechanical brake for weight addition and wheel mounting
* Automatically starts when wheel guard is closed
* LED digital display
* Automatic Rim diameter and Rim width input
* Split weight program (spokes program)
* Optimization program
* Wheel seating cones for LCV are supplied as optional
Additional features for Premium+ models * Laser line indication to indicate weight fixing position (for Sticker weights)
* Torch light for illumination of the Inner plane during weight fixing
Rim Diameter | 24" |
Brand | Manatec |
Rim Width | 20" |
Max Wheel Diameter | 990 mm |
Max Wheel Weight | 65 kg |
Motor Power | 0.35HP |
Power Supply | 230V AC |
Model Name/Number | DL-65 Premium |
Balancing speed | 175 RPM |
Power | 0.35HP |
Spin time | Min. 9 sec. |
Accuracy | 1 gm |
Maximum unbalance measurement | 300 gm |
Resolution Fine mode | 1 gm |
Resolution Normal Mode | 5gm |
Rim distance By distance measuring rod | 300 mm |
Rim distance by keypad entry | 550 mm |
Maximum wheel width | 533 mm |
Country of Origin | Made in India |
